Specifikacija
Ključne karakteristike
- Two independently controllable climate zones from 5° to 20°.
Highlights
- Opening assist for door enabling seamless integration without handles.
- 2 independently controllable climate zones.
- Consistent temperatures with exact control from +5 °C to +20 °C.
- Humidity control.
- Extendable bottle trays made of oak wood and aluminium.
- Adjustable LED lighting.
- Cushioned door closing system allowing a soft and controlled door closure.
- Capacity: 38 bottles (based on 0.75 l standard bottles).
- Side-by-side installation possible with special accessory.
Handling
- Opening assist for door.
- Electronic temperature control with digital display.
- Touch keys.
- Presentation light option, dimmable.
- Interior LED lighting (3000 K) with automatic dimming with opening and closing of door.
- Lockable door (with door lock RA 220 010).
Technical features
- Dynamic cold air distribution.
- Automatic defrosting with defrost water evaporation.
- Constant air purification by activated charcoal air filter in each climate zone.
- UV protection (UV transmission: 19 %).
- Rest mode certified by Star-K.
- When rest mode is active, the appliance can only be opened using a handle.
- Open-door and malfunction alarm.
Features
- 5 bottle trays, thereof 4 extendable.
- Storage of Magnum bottles possible (up to 4 Magnum bottles).
- LED lighting.
- Total volume: 101 litres.
Consumption data
- Energy efficiency class: F (at a range of energy efficiency classes from A to G).
- Energy consumption: 105 kWh/year.
- Noise level: 34 dB(A) re 1 pW.
Planning notes
- Flat hinge.
- Door hinge: right, reversible.
- Height-adjustable feet.
- Door opening angle: 115°, fixable at 90°.
- Max. door panel frame weight: 10 kg.
- For integration next to a side wall a clearance of 7 mm/238 mm hinge side is necessary for door panel thickness of 19 mm without handle and a door opening angle of 90°/115°.
- No transport/operation above 1500 m sea level.
Connection
- Total connected load: 0.130 kW.
- Connecting cable: 2.2 m with plug.
