Specifikacija
Ključne karakteristike
- Design your ideal cooling system with multiple combination options.
- Maximized aesthetics with a concealed display.
- Always enjoy fresh ice cubes without compromising on freezing space.
- Opening assist for door enabling seamless integration without handles.
- Maintain your precious ingredients at their best, reducing freezer burn and oxidation, with precision technology.
Highlights
- Dark brushed stainless steel interior, refined with solid anthracite aluminium elements.
- Warm white and glare-free LED light concept for optimal food presentation in all compartments.
- Opening assist for door with two options:
- Push-to-open function for integration into handleless furniture front.
- Pull-to-open function to facilitate opening the door using a handle.
- The drawers in the RVC and RVF models are positioned at the same height. With side-by-side installation, the safety glass shelves and door racks can be aligned on the same level.
- Flexible positioning of shelves and door racks through hidden rail system.
- Flat dark brushed stainless steel inner door.
- Total volume: 516 litres.
Handling
- Opening assist for door.
- Cushioned door closing system.
- User guidance through light and display response to drawer interaction.
- Automatic brightness adjustment based on ambient illumination.
- Hidden touch display.
Technical features
- Dynamic cold air distribution.
- Automatic defrosting with defrost water evaporation.
- Rest mode certified by Star-K.
- When rest mode is active, the appliance can only be opened using a handle.
- Open-door and malfunction alarm.
- Selected digital services (Gaggenau Home Connect):
- Remote control and monitoring.
- Software updates.
Freezing
- No-frost technology with fast freezing at -30 °C.
- 4-star freezer compartment.
- Temperature adjustable from -24 °C to -16 °C.
- Freezer burn protection.
- Oxidation protection.
- Freezing capacity: 25 kg / 24 h.
- Storage time after a malfunction: 19 h.
- Warm-white, glare-free LED lighting: 3000 K.
- 3 aluminium-framed safety glass shelves, individually adjustable in height.
- Flexible positioning of door racks through hidden rail system.
- 4 height-adjustable door racks.
- 3 fully extendable drawers, with cushioned closing system.
Ice maker
- Hidden in one drawer for optimised usable space.
- With fixed water connection (inlet).
- Can be switched off.
- Ice cube production: approx. 2.4 kg / 24 h.
- Removable ice storage container with approx. 3 kg capacity.
- Integrated, easy accessible ice cube scoop.
- Particle filter for water inlet, integrated in ventilation grille area.
- Saturation indicator shown in touch display.
Consumption data
- Energy efficiency class: D (at a range of energy efficiency classes from A to G).
- Energy consumption: 277 kWh/year.
- Noise level: 38 dB(A) re 1 pW.
Planning notes
- Flat hinge.
- Door hinge: left, reversible.
- Door opening angle: 115°, fixable at 90°.
- Max. door panel weight: 39 kg.
- Shut-off valve for water connection must be planned next to the appliance and always be accessible.
- If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Connection
- Total connected load: 0.300 kW.
- Connecting cable: 3.0 m, pluggable.
- Water inlet.
- Supply hose: 1.8 m with 3/4" connection.
- Water pressure: 2 bar to 8 bar.
